    Heavy Duty Special Purpose Dry Powder Foam and Water Tanker Fire Pumper Truck

    Ask Lasest Price
    Brand Name : Mercedes benz
    Model Number : JDX5280TXFGP100/B
    Certification : ISO9001/CCC
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 90 days after sign contract
    Supply Ability : 300 units/year
    • Product Details
    • Company Profile

    Heavy Duty Special Purpose Dry Powder Foam and Water Tanker Fire Pumper Truck

    Six Seats 6X4 Drive Heavy Duty Special Purpose Dry Powder Foam and Water Tanker Fire Pumper Truck

    .Chassis

    ManufacturerMercedes benz
    ModelActros3344
    Drive6x4
    CabMercedes Actros middle-sized cab
    Crew department4 passengers, with 4 air breathing apparatus at the back row
    Wheelbase4500+1350 mm
    Engine max. power320kw/440hp
    Chassis net weight9340kg
    Max. allowable load33000kg
    Max. speed100km/h
    Min. turning diameter<19.8m
    EngineV type, 6 cylinder inline turbo, middle cool diesel engine
    ModelMercedes OM501LA
    Max. power320kw/ 1800r/min
    Max. torque2100 N.M /1080 rpm
    Emission standardEuro 4, use Blue-Tec SCR catalyze technology
    ClutchSingle dry clutch 430mm
    GearboxMercedes G240-16, full synchronizing, 16 forward gear, speed ratio 11.7-0.69, 2 reverse gear
    PTO modelNMV200 full power
    Speed ratio1.48
    Tyre315/80R22.5

    Pump drive system of fire pumper truck

    PTO

    • NMV200(full power PTO)

    Tanks

    Capacity(kg): water: 7000 foam: 1000

    Material: High quality stainless steel 304 ,bottom plate thickness: 4mm,dummy plate thickness: 3mm


    Structure: tanks are equipped with vertical and horizontal anti-swing plates.

    Equipment: 2 entrance holes

    2 overflow devices

    2 water lever sensor

    2 drains mounted with DN50 valve

    4 DN80 filling pipe end


    Technical requirements: in line with the relevant provisions of GA39.4-92


    FAQ

    1. Q: Why should we choose you ?

    A: a. We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.

    b. We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.

    c. We have our own R&D team, production workshop, QC management team,international marketing team and after service team.


    2. Q:What's the delivery time?

    A: a. 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.

    b. ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.

    c. European brand chassis 9 months upon receipt of advance deposit.


    3. Q:What's your payment method?

    A: T/T and L/C are preferred.


    4.Q:Do you arrange shipment for the vehicles?

    A:Yes, we can arrange shippment based on trade terms.


    5. Q: How is the packing?

    A:All the packing comply with exporting standard.

    Any other questions, please do not hesitate to contact with us.
