High Capacity Pumper Stainless Steel Water Tanker Fire Trucks Power 265KW

Ask Lasest Price
Brand Name :	CIMC Jindun
Model Number :	JDX5280GXFSG120/B
Certification :	ISO9001,CCC
Price :	Factory price, Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :	90 days after sign contract
Supply Ability :	300 units/year

Add to Cart

Product Details
Company Profile

High Capacity Pumper Stainless Steel Water Tanker Fire Trucks Power 265KW

Vehicle

Dimension (L×W×H)	9720×2500×3700 (mm)
Gross weight	28000 (kg)
Complete vehicle shipping mass	15350 (kg)
Seat (inc. driver)	2
Max. power	265kw

Chassis

Manufacturer	Daimler
Model	Actros3336
Drive type	6x4
Cab	Flattop Four door lengthen cab
Wheelbase	4500+1350mm
Max. speed	95km/h
Min. turning diameter	≤21m
Approach angle	17°
Departure angle	13°
Engine type	In-line six-cylinder, turbo inter-cooling, electronic unit pump diesel engine
Model	OM501LA.IV/2
Max. torque	1850N.M
Emission standard	China IV/euro IV
Clutch	Monolithic, Dry
Gearbox	Manual, 16 forward gear

Pump drive system

Model	NMV200
Transmission shaft	High balance precision transmission shaft, use intermediate support connection

Side girder

Features: made of welding high quality profiled steels, two longitudinal beams through a plurality of beam intensity bearing joint of high strength bolt connection. The side beam is installed, use girder structure, to ensure that the original car beam of uniform stress, improve the service life of the girder, and reduce deformation caused by components twisted.

FAQ

1, Q: Why should we choose you ?

A: We are professional manufacture located in Shanghai city for firefighting trucks
products which nearby Pudong International Airport, is easily for customer coming
and visiting.

B: We can export directly to overseas customer, no need to deal with trading company
and the second price increase will not occur

C: We have our own R&D team, production workshop, QC management team,
international marketing team and after service team.

D: We will provide the most professional and the best service on every business
discussion and operation procedure.

E: We can provide special design for different specification requirement according to
different orders or tender documents.

G: We have jointed ventures with Morita for 4 years, so the technology, design and
quality are same with Morita.

H: We have collaboration with various top enterprises of fire protection sector, Such as
Darley, Rosenbauer, HALE, AKRON, Ekhart, etc.

I: Our Certifications: ISO, TUV, CCCF, SONCAP, CNAS, SGS,MH /T5002-9, MEP, CQC.

2, Q: What's your Payment method?

A: T/T 30% deposit, balance will be paid by T/T before delivery

B: 100% L/C before start production
