    Seven Seats Fire Command Vehicles Rear Overhang 1680mm With Mounted Electric Generator

    Ask Lasest Price
    Brand Name : IVECO
    Model Number : JDX5040TXFTZ1000
    Certification : ISO9001, CCC
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 300units/year
    Delivery Time : 90days
    • Product Details
    • Company Profile

    Seven Seats Fire Command Vehicles Rear Overhang 1680mm With Mounted Electric Generator

    4x2 drive 7 seats 115km/h IVECO chassis Communication command fire truck


    Dimension (L×W×H)6095×2000×3260mm
    Gross weight4000kg
    Complete vehicle shipping mass3925kg
    Communication command equipment total power1000w
    Seat (inc. driver)1
    Approach angle20°
    Departure angle10°
    Front/ rear overhang1000/1680mm

    Chassis

    ManufacturerNanjing automobile(group) corporation
    ModelNJ6606DA6
    Drive type4x2
    Cab570101AB
    Wheelbase3310mm
    Max. speed115km/h
    Min. turning diameter<12
    Engine typeIn-line four-cylinder, pressure combustion, high pressure common rail, inter-cooling, direct injection diesel engine
    ModelF1CE0481P
    Max. power107kw
    Max. torque327N•m
    Emission standardChina IV
    ClutchMonolithic, dry, diaphragm ring
    Gearbox modelManual, 5 forward gear
    Steering gearPinion and rack

    Vehicle-mounted electric generator

    ModelHONDA EL6500CXS
    Rated power5 kw
    Voltage220V
    Frequency50HZ
    FuelGasoline
    Fuel tank capacity25L
    Continuous working hours8 hours

    Equipment According to customers requirements, equipped with various kinds of communication equipments, stretcher and medicine cabinet, etc.
