25 Meters Max Height Short Adjustment Time Aerial Ladder Fire Truck 4x2 Drive​​

Main parameters and configuration

1, vehicle

1.1 dimensions: length * width * width * height (mm) 8650 * 2450 * 3500

1.2 full load allowed total mass (kg): 17400

1.3 vehicle kerb mass (kg): 15700

1.4 the number of passengers (including the driver) (person): 2

1.5 maximum power (kW/hp): 177/240

2, chassis

2.1 manufacturer: Isuzu

2.2 Isuzu FTR34L

2.3 drive form: 4X2

2.4 cab: single row cab

2.5 wheelbase (mm): 4250

2.6 chassis weight: 4710 Kg

2.7 maximum allowable load: 12700Kg

2.10 engine: 6 cylinder diesel engine

2.11 type: 6HK1-TCN

2.12 maximum engine power: 177Kw/ 2400r/min

2.13 maximum torque: 706N.M/1450rpm

2.15: single, dry clutch

2.16 transmission: MZW6P

2.17 taking full power: broken shaft type

2.18 transmission power: customers with

tools

Shanghai Jindun special vehicle Equipment Co., Ltd.​ is a high-tech special vehicle enterprise and flagship company of jindun group. It owns first class factory, internationally advanced processing equipment, gathers many top technicians and industrial experts, establishes national grade technology R&D center, and has 112 types of products, including truck crane, aerial working platform truck, road wrecker truck, road maintenance truck, dump truck, CAFS fire trucks, chenical fire truck, water tank foam trucks, emergency rescue vehicles, gas supply vehicles, lighting truck, satellite communication command vehicle, road-rail convertible vehicle, aerial ladder trucks, aerial platform truck, airport fire trucks, long distance water supply truck, water tower fire truck and other general fire trucks.

    Our company regards technological progress as the driving force for the development of enterprises. At the same time, the company improves the capability of independent research and development, constantly improves the technology content of products, and introduces new products. In order to ensure product quality reliability, the company has carried out experimental and simulated assembly for the key parts of the company, 100% to improve the stability of the product. Strong new product research and development force, stable and reliable product quality, good commercial reputation, efficient enterprise management, promote the continuous development among the advanced ranks of fire truck industry.
