    100km/h 4x2 Drive 6 Cylinder Diesel Engine 25 Meter Aerial Ladder Fire Truck

    Ask Lasest Price
    Brand Name : CIMC Jindun
    Model Number : DG25
    Certification : ISO9001,CCC
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 300 units/year
    Delivery Time : 90 days after sign contract
    • Product Details
    • Company Profile

    100km/h 4x2 Drive 6 Cylinder Diesel Engine 25 Meter Aerial Ladder Fire Truck

    100km/h 4x2 Drive 6 Cylinder Diesel Engine 25 Meter Aerial Ladder Fire Truck


    Main parameters and configuration

    1, vehicle

    1.1 dimensions: length * width * width * height (mm) 8650 * 2450 * 3500

    1.2 full load allowed total mass (kg): 17400

    1.3 vehicle kerb mass (kg): 15700

    1.4 the number of passengers (including the driver) (person): 2

    1.5 maximum power (kW/hp): 177/240

    2, chassis

    2.1 manufacturer: Isuzu

    2.2 Isuzu FTR34L

    2.3 drive form: 4X2

    2.4 cab: single row cab

    2.5 wheelbase (mm): 4250

    2.6 chassis weight: 4710 Kg

    2.7 maximum allowable load: 12700Kg

    2.10 engine: 6 cylinder diesel engine

    2.11 type: 6HK1-TCN

    2.12 maximum engine power: 177Kw/ 2400r/min

    2.13 maximum torque: 706N.M/1450rpm

    2.15: single, dry clutch

    2.16 transmission: MZW6P

    2.17 taking full power: broken shaft type

    2.18 transmission power: customers with


    Equipment & Spare parts

    noname and modelunitqty.remarks
    1o ring 14×2.65Gpcs6GB/T3452.1-1992
    2ring 11.2×2.65Gpcs4GB/T3452.1
    3ring 22.4×2.65Gpcs4GB/T3452.1
    4ring 71×3.55Gpcs1GB/T3452.1
    5ring 118×5.3Gpcs1GB/T3452.1
    6ring 150×3.55Gpcs1GB/T3452.1
    7ring 140×5.3Gpcs3GB/T3452.1
    8ring 128×5.3Gpcs1GB/T3452.1
    9checking switch SZL-WL-Apcs1
    10travel switch SZL-WL-Bpcs1
    11travel switch SZL-WL-EPcs1
    12fuse tube 5×20Pcs1010A
    13fuse tube 5×20pcs2020A

    Tools

    No.name and modelUnitqty.remarks
    1internal hexagonal wrench3~17suit1GB/T5356-1998
    2monkey wrench150×18pcs1GB/T4440-1998
    3monkey wrench300×36pcs1QB/T2564.4-2002
    4straight screwdriver50×0.4×2.5I-1Ppcs1QB/T2564.4
    5

    straight screwdriver

    125×0.8×5.5I-1P

    pcs1QB/T2564.4
    6straight screwdriver250×1.6×10I-1Ppcs1QB/T2564.4
    7cross screwdriver175Cpcs1QB/T2564.4
    8cross screwdriver3150C-Hpcs1QB/T2564.4
    9press bar type grease gunpcs1QB/T2564.4
    10hammer 0.88kgpcs1QB/T2564.4
    11wire cutter 180mmpcs1QB/T2564.4
    12pipe wrench 300 Ⅲ Zpcs1QB/T2564.4
    13slip-joint plier165mmpcs1QB/T2564.4
