    ISUZU Chassis 4x2 Drive 22M Telescopic Boom Truck Mounted Aerial Platforms 90km/H

    Ask Lasest Price
    Brand Name : KaiFan
    Model Number : KFM5075JGK –GKS-22Q
    Certification : IQNET,ISO
    Price : Factory price, negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 350 /year
    Delivery Time : Three months
    • Product Details
    • Company Profile

    ISUZU Chassis 4x2 Drive 22M Telescopic Boom Truck Mounted Aerial Platforms 90km/H

    ISUZU Chassis 4x2 Drive 22M Telescopic Boom Truck Mounted Aerial Platforms 90km/H


    A,Working Condition

    1,Altitude: 0-1000m.

    2,Temperature: -25℃--+45℃, environmental relative humidity ≤90%.

    3,Allowed working condition: solid, stable land, the vehicle should be horizontal.

    4,Wind force: ≤6 degree (wind speed ≤12.5m/s).


    B,Working Range

    KFM5075JGK Telescopic Boom Aerial Working Platform can be applied in various conditions for aerial working, such as urban road, suburban road, highway, airport, bridges and culverts and so on. The structure type is telescopic boom and the lifting boom is flexible, convenience and performance with the negative point, more suitable for narrow site conditions or other special operations.


    C,Main Parameters

    Bulletin No.KFM5075JGK
    TypeGKS-22Q
    External dimensions(mm)7150×2045×3550
    Structure typeFour-section telescopic boom
    Working CageInternal size(mm)1000×650×1100
    Rated loading(kg)200(or 2 persons)
    Max. Working height(mm)22000
    Max. Height from ground(mm)20300
    Rotation angle(º)Left 90 º, right 90 º
    Max. Working radius(mm)13400
    Working radius when doing the highest height(mm)4190

    Working Boom

    Lifting angle(º)-12~80
    Out rate speed(mm/sec)12360/70
    Ret rate speed(mm/sec)12360/70
    Boom rack rotation angle(º)360
    Boom rack rotation speed(r/min)1.0
    Outrigger

    Vertical span(mm)

    4000
    Horizontal span(mm)4000
    Traveling of vertical outrigger(mm)550
    AdjustmentSingle adjustable

    D,Chassis Introduction


    Traveling

    Performance

    Parameters

    Chassis modelISUZU NKR77LLPACJAY (EN III)
    Persons2
    Axle base (mm)3360
    Wheel base (front/rear)(mm)1504/1425
    Driving mode4×2
    Front suspension(mm)1015
    Rear suspension(mm)2100
    Approaching angle(º)24
    Departure angle(º)12
    Max. Grade ability(%)28
    Min. Turning diameter(mm)13600
    Min. Ground clearance(mm)190
    EngineEngine model4KH1-TC
    Rated power(kw/r/min)96/3400
    Torque(N,m/r/min)280/1700



    Max. Speed(km/h)

    90
    Gas consumption per one hundred miles(diesel oil) (L)12
    Specification of the tire7.50-15,7.50R15,7.00-16,7.00R16
    The whole weight(kg)7170
    Max. Weight with whole loading(kg)7300
