ISUZU Chassis Two Person Crew 22 Meters Aerial Work Platform Truck

Four-section telescopic boom ISUZU chassis 4x2 drive 22M Aerial Working Platform 90km/h speed 200kg load

A,Working Range

KFM5075JGK Telescopic Boom Aerial Working Platform can be applied in various conditions for aerial working, such as urban road, suburban road, highway, airport, bridges and culverts and so on. The structure type is telescopic boom and the lifting boom is flexible, convenience and performance with the negative point, more suitable for narrow site conditions or other special operations.

B,Main Parameters

Bulletin No.		KFM5075JGK
Type		GKS-22Q
External dimensions(mm)		7150×2045×3550
Structure type		Four-section telescopic boom
Working Cage	Internal size(mm)	1000×650×1100
	Rated loading(kg)	200(or 2 persons)
	Max. Working height(mm)	22000
	Max. Height from ground(mm)	20300
	Rotation angle(º)	Left 90 º, right 90 º
	Max. Working radius(mm)	13400
	Working radius when doing the highest height(mm)	4190
Working Boom	Lifting angle(º)	-12~80
	Out rate speed(mm/sec)	12360/70
	Ret rate speed(mm/sec)	12360/70
	Boom rack rotation angle(º)	360
	Boom rack rotation speed(r/min)	1.0
Outrigger	) Vertical span(mm)	4000
	Horizontal span(mm)	4000
	Traveling of vertical outrigger(mm)	550
	Adjustment	Single adjustable

C,Chassis Introduction

Traveling Performance Parameters	Chassis model	ISUZU NKR77LLPACJAY (EN III)
	Persons	2
	Axle base (mm)	3360
	Wheel base (front/rear)(mm)	1504/1425
	Driving mode	4×2
	Front suspension(mm)	1015
	Rear suspension(mm)	2100
	Approaching angle(º)	24
	Departure angle(º)	12
	Max. Grade ability(%)	28
	Min. Turning diameter(mm)	13600
	Min. Ground clearance(mm)	190
Engine	Engine model	4KH1-TC
	Rated power(kw/r/min)	96/3400
	Torque(N,m/r/min)	280/1700
Max. Speed(km/h)		90
Gas consumption per one hundred miles(diesel oil) (L)		12
Specification of the tire		7.50-15,7.50R15,7.00-16,7.00R16
The whole weight(kg)		7170
Max. Weight with whole loading(kg)		7300

D,Vehicle Information

Manual Instruction
Operation manual of chassis
Guarantee of chassis
Certification of quality of the vehicle
Maintenance Manual (Operation instruction)
Operating safety certification
