KaiFan Heavy Duty H Series VOLVO Chassis Road Wrecker Truck 3 Person 8x4 Drive

Shanghai Jindun special vehicle Equipment Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap KaiFan Heavy Duty H Series VOLVO Chassis Road Wrecker Truck 3 Person 8x4 Drive from wholesalers

    Buy cheap KaiFan Heavy Duty H Series VOLVO Chassis Road Wrecker Truck 3 Person 8x4 Drive from wholesalers
    • Buy cheap KaiFan Heavy Duty H Series VOLVO Chassis Road Wrecker Truck 3 Person 8x4 Drive from wholesalers
    • Buy cheap KaiFan Heavy Duty H Series VOLVO Chassis Road Wrecker Truck 3 Person 8x4 Drive from wholesalers

    KaiFan Heavy Duty H Series VOLVO Chassis Road Wrecker Truck 3 Person 8x4 Drive

    Ask Lasest Price
    Brand Name : KaiFan
    Model Number : KFM5442TQZ–SQZ1860HV
    Certification : IQNET,ISO
    Price : USD
    Payment Terms : T/T
    Supply Ability : 300/year
    Delivery Time : 3months
    • Product Details
    • Company Profile

    KaiFan Heavy Duty H Series VOLVO Chassis Road Wrecker Truck 3 Person 8x4 Drive

    99 km/h max speed KaiFan Heavy-duty H Series VOLVO chassis Road Wrecker 3 person 8x4 drive

    A,Working Condition
    1,Altitude: 0-4500m
    2,Temperature: -35℃--+45℃
    3,Relative humidity: 80%
    4,Wind force: ≤8degree



    B,Working Range
    KFM5442TQZ Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind

    C,Main Parameters

    ItemsUnitValue
    Lifting StructureRated Lifting weightkg13765
    Max. Lifting weight of original placekg18000
    Max. Lifting weight of full extension boomkg8000
    Rated towing weightkg44000
    Max. Designed towing weightkg60000
    Effective length of boommm3350
    Extension traveling of boommm1700
    Folding angle of boom°90
    Under lift StructureMax. Rated hanging weightkg25000
    The height from hook to the groundmm13430
    Max. Extension traveling of lifting boommm6000
    Rotation angle°360
    Numbers of winchpiece2
    Rated pulling power of winchkg2×15000
    Dia. Of steel cablemm22.4
    Length of steel cablem40
    Min. Speed of steel cablem/min4
    Rotation angle°65

    Vehicle
    Parameters

    External dimensionmm10741×2500×3366
    Chassis modelFM400 84RB
    Drive8×4
    Axle basemm1995+4405+1370
    The whole weight of empty loadkg30040
    Load of front axle of empty loadkg14380
    Load of rear axle of empty loadkg15660
    The whole weight of full loadkg44000
    Load of front axle of full loadkg9000/9000
    Load of rear axle of full loadkg13000/13000
    Wheel base (front/rear axle)mm2019/1834
    Front suspensionmm1362
    Rear suspensionmm935
    Approach angleº16.6
    Departure angleº20
    Min. Turning diameterm24.6
    Min. Ground clearancemm306
    Max. Speedkm/h99
    Grade ability%30
    Gas consumption per one hundred miles(diesel oil)L35.4
    Engine model-D13
    Engine emissionL12.8
    Rated powerkw/r/min400/294/1400~1800
    Torquen·m/r/min2000/1050~1400
    Fuel typeDiesel
    Standard of emissionEN III
    Tire size315/80R22.5
    Persons3
