    Full Load 54000KG Road Wrecker Truck 10×4 Drive Truck VOLVO FM440 104RB

    Ask Lasest Price
    Brand Name : KaiFan
    Model Number : KFM5071TQZ13P –SQZ1503PO
    Certification : IQNET,ISO
    Price : USD
    Payment Terms : T/T
    Supply Ability : 300/year
    Delivery Time : 3months
    • Product Details
    • Company Profile

    Full Load 54000KG Road Wrecker Truck 10×4 Drive Truck VOLVO FM440 104RB

    The whole weight of full load 54000KG Road Wrecker Truck 90km/h 11342×2500×3710mm 10×4 Drive


    1,Standard Equipments

    1. VOLVO FM440 104RB

    2. Main boom structure assembly

    3. Vice boom assembly

    4. Hanging hook assembly

    5. Control structure assembly

    6. Chain wheel and hanging assembly

    7. Winch assembly (include winch clutch, impaction device)

    8. Steel body assembly

    9. Tool box assembly

    10. Light stands assembly

    11. Alarm device

    12. Hydraulic system

    13. Hydraulic system over voltage protection device

    14. Electric system

    15. PTO Warner


    2,Working Condition

    1,Altitude: 0-4500m

    2,Temperature: -35℃--+45℃

    3,Relative humidity: 80%

    4,Wind force: ≤8degree


    3,Main Parameters

    ItemsUnitValue
    Lifting StructureRated Lifting weightkg15815
    Max. Lifting weight of original placekg35000
    Max. Lifting weight of full extension boomkg12500
    Rated towing weightkg54000
    Max. Designed towing weightkg80000
    Effective length of boomm3670
    Extension traveling of boomm1850
    Folding angle of boom°90
    Under lift StructureMax. Rated hanging weightkg40000
    The height from hook to the groundmm13500
    Max. Extension traveling of lifting boommm6000
    Rotation angle°360
    Numbers of winchpiece2
    Rated pulling power of winchkg25000
    Dia. Of steel cablemm26
    Length of steel cablem45
    Min. Speed of steel cablem/min4
    Rotation angle°65

    Vehicle

    Parameters

    External dimensionmm11342×2500×3710
    Chassis modelFM440 104RB
    Drive10×4
    Axle basemm1995+2805+1400+1370
    The whole weight of empty loadkg38055
    Load of front axle of empty loadkg16885
    Load of rear axle of empty loadkg21170
    The whole weight of full loadkg54000
    Load of front axle of full loadkg9000
    Load of rear axle of full loadkg10000/13000
    Wheel base (front/rear axle)mm2029/1875
    Front suspensionmm1362
    Rear suspensionmm1750
    Approach angleº16.6
    Departure angleº20
    Min. Turning diameterm27.2
    Min. Ground clearancemm306
    Max. Speedkm/h90
    Max. Grade ability%25
