265kw Mercedes Benz Chassis 6x4 Drive Water Tanker Fire Truck
12000kg Tank
The SG120/B 12000kg water tank fire truck is modified from the
Actros 3336 chassis produced by Daimler AG. The overall layout of
the vehicle is reasonable. The equipment compartment, tank, and
pump room adopt a split structure, with a novel and coordinated
appearance. The vehicle equipped with R600 fire pump and the
PLC6000 roof monitor. The structure is compact, and the operation
and maintenance are very convenient.
Vehicle
| Dimension (L×W×H) | 9720×2500×3700 (mm) |
| Gross weight | 28000 (kg) |
| Complete vehicle shipping mass | 15350 (kg) |
| Seat (inc. driver) | 2 |
| Max. power | 265kw |
Chassis
| Model | Actros3336 |
| Drive type | 6x4 |
| Cab | Flattop Four door lengthen cab |
| Wheelbase | 4500+1350mm |
| Max. speed | 95km/h |
| Min. turning diameter | ≤21m |
| Approach angle | 17° |
| Departure angle | 13° |
| Engine type | In-line six-cylinder, turbo inter-cooling, electronic unit pump
diesel engine |
| Model | OM501LA.IV/2 |
| Max. torque | 1850N.M |
| Emission standard | China IV/euro IV |
| Clutch | Monolithic, Dry |
| Gearbox | Manual, 16 forward gear |
Fire pump
| Model | R600 |
| Pressure/ Flow | 1.0MPa/90L/s |
| Primer type | Piston primer pump |
| Max. vacuum degree | ≥85 kPa |
| Priming time | ≤80s |
| Air foam proportioner | PH48, manual, mixing ratio:3%, 6% |
Fire monitor
| Model | POK, PLC6000 |
| Position | At the top of rear vehicle |
| Flow | 1.0MPa/80L/s |
| Range | water≥80m ,foam≥50m |
| Rotation angle | Level≥270° Max. elevation angle≥+45° Max. depression angle≥-7° |
Liquid tank
| Capacity | Water: 12000kg |
| Material | 304 high quality corrosion resistant plate |
| Structure | Total side girder |
| Device | 1 ingate 1 overflow device 1liquid level sensor 1 DN50 drain outlet with valve 4 filling pipe end Conform to rule GA39.4-92 |
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the
biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
6. Q: What's the delivery time?
A: 1) 20 days delivery upon receipt of advance deposit if we have
ready in stock for normal standard model.
2) ISUZU & Chinese brand chassis 3 months upon receipt of advance
deposit.
3) European brand chassis 9 months upon receipt of advance deposit.
Any other questions, please do not hesitate to contact with us.
