369Kw 8x4 Drive Water Tower Fire Truck Fire Engine Vehicle 60m Working height

Ask Lasest Price
Brand Name :	CIMC
Model Number :	JP25
Certification :	ISO9001,CCC
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	300 units/year
Delivery Time :	120 days

Add to Cart

Product Details
Company Profile

369Kw 8x4 Drive Water Tower Fire Truck Fire Engine Vehicle 60m Working height

369Kw 8x4 Drive Water Tower Fire Truck Fire Engine Vehicle 60m Working height 315L Fuel Tank M Cab

JP60 Model water tower fire truck is modified from VOLVO chassis, 8x4 drive. The Water tower fire vehicle equipped with 369kw powerful engine, hydraulic tilting cab, imported fire monitor and fire pump. It is the most advanced world class fire-fighting truck adopting PLC automatic computerized control technology is very effective and safe for rescue and fire-fighting application particularly for high rise buildings in the city ,oil industries, chemical, oil tank and some storage.

Vehicle name			SXT5411JXFJP60 water tower fire truck
chassis	Chassis name		VOLVO FM500 84R B
	Driving		8×4
	Wheelbase		1995+4205+1370mm
	engine		D13C,Euro V emission standard, turbo , diesel engine in line.
	Engine power		500hp/369Kw/1,400-1,900rpm
	Engine capacity		12 L
	Fuel tank		315 L
	tire		Front tires: 385/65 R22.5 4 pieces Rear tires: 315/80 R22.5 8 pieces Back up tires: 315/70 R22.5 1 pieces
	Battery box		110A generator,2X12V/170AH battery
	cab		M-cab,1+1 seating
	Hydraulic tilting type VOLVO safety cab, comfortable (suspension) driver seat, fire red paint, radio, CD player, hot and cold air conditioning system, central door lock, electric doors and Windows, electric rearview mirror, front view mirror, driving outdoor visor, safety belt. Integrated power steering, cruise control system, real-time monitoring system for vehicle operation, engine start preheater, reversing warning device, oil and water separator for fuel system, brake air dryer, etc.
dimension:(L×W×H)				13160×2500×3845mm
Gross weight		42600kg
Max. running		≥85km/h
outtrigger		structure			H style
		longitudinal			8970mm
		transverse			5600mm

Fire monitor	American Elkhart:Scorpion RF 8294-06/SM-1250E,water/foam use electronic control monitor. Flow adjustment 1150——4800L/min；working pressure 0.55MPa. reach(water)≥70m. reach(foam)≥60m (the reach will be different depending on water flow) Swivel angle ±45 degree； up angle 90 degree；depression angle 45degree. ≥100 m wireless control .
Foam Monitor head	self made foam monitor head
Water way control	Control mode: air drive control
Water way control	control panel position: left side of vehicle
Monitor protection	water spray curtain system to protect monitor, electric control
Fire plumbing	Down part:stainless pipe+aluminium pipe
Fire plumbing	Upper :telescopic water pipe:aluminium alloy seamless tube Soft connection pipe: soft rubber tube
Water coupling	coupling	specification	valve
	External Water Supply	4XDN80	Manual ball valve
	External water suction	2XDN150	with lid cover
	Tank Internal Suction	1XDN200	Pneumatic butterfly valve
	Tank water supply	1XDN65	Pneumatic butterfly valve
	Water outlet	4XDN80	Manual ball valve
	Upper Monitor inlet	1XDN125	Pneumatic butterfly valve
	Water supply from end of vehicle	4XDN80	Manual ball valve with cover
	Water Tank Drainage	1XDN50	Manual ball valve with interface
	External Foam Suction	1XDN50	Manual ball valve with cover
	External Foam filling	1XDN50	Manual ball valve with cover
	Foam Tank Drainage	1XDN50	Manual ball valve with interface

FAQ:

1. Q:Are you a factory or a trade company?

A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.

2. Q:Where is your factory located?

A:We are located in Shanghai Province,China.

3. Q:What's your payment method?

A: T/T and L/C are preferred.

4.Q:Do you arrange shipment for the vehicles?

A:Yes, we can arrange shippment based on trade terms.

5. Q: How is the packing?

A:All the packing comply with exporting standard.

6. Q: What's your main product?

A: Our main product include : water & foam tank trucks, CAFS fire trucks, chemical fire trucks, emergency rescue vehicles, lighting trucks, aerial ladder and platform trucks, airport fire trucks, water tower fire trucks and other general fire trucks. The products have been sold to more than 20 countries.

Any other questions, please do not hesitate to contact with us.
