70m Working Height 8x4 32350kg Remote Control Rescue Aerial Ladder Fire Truck

Shanghai Jindun special vehicle Equipment Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 70m Working Height 8x4 32350kg Remote Control Rescue Aerial Ladder Fire Truck from wholesalers

    Buy cheap 70m Working Height 8x4 32350kg Remote Control Rescue Aerial Ladder Fire Truck from wholesalers
    • Buy cheap 70m Working Height 8x4 32350kg Remote Control Rescue Aerial Ladder Fire Truck from wholesalers
    • Buy cheap 70m Working Height 8x4 32350kg Remote Control Rescue Aerial Ladder Fire Truck from wholesalers

    70m Working Height 8x4 32350kg Remote Control Rescue Aerial Ladder Fire Truck

    Ask Lasest Price
    Brand Name : Jindun
    Model Number : DG70
    Certification : ISO9001/CCC
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 150 days
    Supply Ability : 350 units/year
    • Product Details
    • Company Profile

    70m Working Height 8x4 32350kg Remote Control Rescue Aerial Ladder Fire Truck

    70m Working Height 8x4 32350kg Remote Control Rescue Aerial Ladder Fire Truck


    DG70 Aerial Platform fire truck is the most advanced world class fire-fighting truck, adopting PLC automatic computerized control technology. The vehicle is very effective and safe for rescue and fire-fighting application particularly for high rise buildings in the city and oil industries. The hydraulic and electrical control system are designed according to the latest international standards, to ensure good functionality, stability, safety and reliability, make this turntable ladder to be the ultimate solution for the actual fire-fighting and rescue of metropolitans, urban and rural areas.


    Vehicle modelDG70
    chassischassisVOLVO FM540 84R(made in Europe)
    Driving8×4
    Wheel base1995+4205+1370mm
    engineEuro V emission standard
    power540hp/397Kw/1,450-1,900rpm
    Engine capacity11.946 L
    Fuel tank315 L tank
    Urea tank48L Adblue urea tank
    tire

    Front wheel: 385/65 R22.5 (4 pieces)

    rear wheel: 315/80 R22.5 (9 pieces)

    spare tire is same with driving wheel

    Battery box110A generator,2X12V/170AH battery
    cabM-cab,1+1 seating

    Hydraulic tilting type VOLVO safety cab, comfortable (suspension) driver seat, fire red paint, radio, CD player, hot and cold air conditioning system, central door lock, electric doors and Windows, electric rearview mirror, front view mirror, driving outdoor visor, safety belt.

    Integrated power steering, cruise control system, real-time monitoring system for vehicle operation, engine start preheater, reversing warning device, oil and water separator for fuel system, brake air dryer, etc

    Foam headEquip with foam monitor head
    Water way control

    Water way control mode:pneumatic control

    The position is left side of vehicle

    Fire

    plumbing

    Down part:stainless pipe + aluminum pipe

    Upper part:

    telescopic water pipe: aluminum alloy seamless tube

    Folding water pipe: aluminum alloy seamless tube

    Soft connection pipe: rubber soft tube

    Water

    coupling

    couplingspecValve
    External Water Supply2XDN80Hose coupling with cover lid
    Upper Monitor inlet1XDN125Pneumatic butterfly valve
    Water supply from end of vehicle2XDN80Manual ball valve with cover
    Coupling type:quick coupling or slow coupling option



    FAQ

    1. Q: Why should we choose you ?

    A: a. We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.

    b. We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.

    c. We have our own R&D team, production workshop, QC management team,international marketing team and after service team.


    2. Q:What's the delivery time?

    A: a. 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.

    b. ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.

    c. European brand chassis 9 months upon receipt of advance deposit.


    3. Q:What's your payment method?

    A: T/T and L/C are preferred.


    4.Q:Do you arrange shipment for the vehicles?

    A:Yes, we can arrange shippment based on trade terms.


    5. Q: How is the packing?

    A:All the packing comply with exporting standard.


    6. Q:What's your main products?

    A:Our main product include : water & foam tank trucks, CAFS fire trucks, chemical fire trucks, emergency rescue vehicles, pumper fire truck, lighting trucks, aerial ladder and platform trucks, airport fire trucks, water tower fire trucks and other general fire trucks. The products have been sold to more than 20 countries.


    Any other questions, please do not hesitate to contact with us.
