    Diesel Fuel Heavy Wrecker Trucks / Flatbed Wrecker Truck 4*2 Drive Heavy Duty

    Ask Lasest Price
    Brand Name : YD
    Model Number : SQZ1860HV
    Certification : ISO9001:2008
    Price : USD
    Payment Terms : T/T, L/C
    Supply Ability : 50 SETS PER MONTH
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    Diesel Fuel Heavy Wrecker Trucks / Flatbed Wrecker Truck 4*2 Drive Heavy Duty

    Stretch Travel Range Of Tow Arm 1180 Flatbed Working Road Wrecker Diesle Fuel


    Feature


    The cab: Dongfeng tractor adopt luxurious cab with the comfortable shock-free driving seat, the electric controlled glass and the central lock device, this guarantee the driving comfortability; At the same time, the knee shield guard improve the security of the driver and the passengers. This cab also bring down the drag coefficient to reduce the fuel consumption.


    The engine: The tractors used Cummins engine which provide excellent gradeability, strong horsepower and bring down the oil consumption, reduce the operating cost for client.


    The chassis: The Dongfeng chassis make the tractors have big ground clearance and excellent trafficability and adaptability to various vile roads.


    The gearbox: The Fast Brand gearbox adopt serration processing technology to lower the noise and vibration and increase the reliability.


    Specification


    VEHICLE MODLEJDF5071TQZ
    OVERALL DIMENSION(mm)7420×2320×2540GVW(Kg)7490
    Cargo body dimension(mm)××Rated payload(Kg)
    approach/depar ture angle20/12Curb weihgt(Kg)5495
    Overhang(front /rear)(mm)1180/2440Max speed(km/h)95
    Chassis modelEQ1070TJ9AD3

    B140 33 YN38PE-2

    Dongfeng Cummins Engine Company

    Kunming Yunei Power Company

    3900 3760103 90
    Fuel typediesleEmissionEuro 23
    Number of axle2Number of tire6
    wheelbase3800Tire size8.25-16,7.50-16,8.25R16,7.50R16
    Axle load(front/rea r)3090/4400Front tread1835,1750

    Number of steel spring leaf

    (front/rear)

    11/9+7,8/10+7Rear tread1640,1586
    special function
    performance

    Rated tow lifting weight(kg):1040 ;

    stretch travel range of tow arm(mm):1180

    maximum effective length of tow arm(mm):1300

    maximum traction speed(km/h):40

    Specification of flat board

    Dimension of flat board(Length*width(mm):5240*2100

    Minimum gradient of flat board(°):10

    work travel range of flat board(mm):2680

    Maximum load weight of flat board(kg):3000

    The specification of the winch qty(piece):1

    rated towing weight(kg):3000 the length of steel wire rope(m):21

    the speed of winch rope(m/min):8
