Multi-purpose 400L Remote Water Supply System Fire Truck with
Crawler Robot
Feature of pump fire truck
1)Water pump, booster pump engine selection of the famous joint
venture brand, large power.
2)Hydraulic oil pump, motor, control valve, hydraulic hose and
other key components of the selection of imported brands, to ensure
reliable hydraulic system.
3)Dual forced cooling is adopted in the engine and hydraulic system
for long time, and the water temperature of the whole power system
is always in the normal range;
4)Equipped with track type water intake module, can be remotely
controlled to the water side, the use of the car with the lifting
arm can be easily put into the water floating boat pump.
5)When intake water in bridge, wharf water, the mid arm long arm
stretch (over 17 meters) will easily float into the water pump.
6),Floating boat pump weight less than 110 kg, equipped with wheels
and protective frame, the implementation of convenient, reliable,
and equipped with 4 handles, easy handling.
Feature of hose laying truck
1)Equipped with automatic collection machine, at the same time with
rolling, cleaning and finishing water function, greatly reduce the
work intensity of operators.
2)Can be achieved at low speed, can be achieved when the 2 ~ 3km/h
low speed of the take-up hose, to avoid the engine, clutch damage
for a long time low speed drive.
3)Hose box surface using vulcanized rubber damping protection
plate, ensure the hose interface deformation, in the recovery
process is not broken.
pumping truck onboard equipment
| Name | Specification | No. | Notes |
|---|
| 1 | Liner hose assembly | 10-250-20 | 2 | |
| 2 | Liner hose assembly | 10-250-10 | 2 | |
| 3 | Liner hose assembly | 10-250-5 | 2 | |
| 4 | Hose connection wrench | General type | 4 | |
| 5 | Vertical water supply bend | DN250 | 2 | |
| 6 | Hydraulic rubber tube protector | General type | 1 | |
| 7 | Highlight flashlight | | 2 | |
| 8 | Handheld anti-explosion interphone | | 1 | |
| 9 | Chassis onboard tools | Standard | | |
