MAN Large Space Cab Foam and Water Tanker Fire Truck close by
Shutter Doors
1. Vehicle
| Dimension | 6870X2240X3040 mm |
| total weight | 6125kg |
| Seat (inc. driver) | 2+3 |
| Max. power | 139kw/189hp |
| Drive | 4x2 |
2. Liquid tank
| capacity | water: 2320L, foam: 1065L |
| Material | Stainless steel plate 304, bottom plate 4mm, side plate and
partition are 3mm. |
| Equipment | 2 inlet holes (450mm) 1 overflow device 1 venting device 2 water level sensors 2 drain outlets with valves 2 external water inlets (string top type) 1 inner water inlet |
| Technical requirements | Meet the relevant provisions of 4.4.3 of GB7956.3-2014 |
3. Equipment box and pump room
| Material | Q235A high quality steel |
| Structure | The welding, lap joint structure, skin, bottom plate and interior
panel are all anodized LF2 rust-proof flat aluminum plate. |
| Equipment door | Lightweight and high quality aluminum alloy shutter door, light and
reliable |
| Internal structure | The inner skeleton C-type rail steel combined with the introduction
of the aluminum technology lap joint technology developed by German
technology can maximize the space utilization and variability. The structure is beautiful in appearance and convenient to pick and
place equipment. A hand lift pump drawing plate is added on the left side of the
equipment box, and an aluminum adjustable equipment box is added on
the upper part of the right side of the equipment box, and a simple
rescue tool can be arranged inside the equipment box. |
4. Electrical System
The main warning light at the top of the cab is a red long row of
warning lights, equipped with a 100W alarm control system; two
strobe lights are installed on each side of the compartment, LED
side lights are installed on both sides of the vehicle, and safety
sign lights are installed below; One 24V, 35W LED remote search
light is installed at the back of the top;
5. Dashboard and board equipment
5.1 pump room
5.2 Function switch: Meter power switch and indicator
Water diversion switch and indicator
Equipment box light switch and indicator light
5.3 Instrument: Pressure gauge
Pressure vacuum meter
Water level gauge
Level table
Tachometer
Water temperature gauge
Oil temperature gauge
