    6×4 Driving Single Cab Hydraulic Aerial Ladder Fire Truck with full power PTO

    Ask Lasest Price
    Brand Name : Jindun
    Model Number : DG44
    Certification : ISO9001/CCC
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 90 days after sign contract
    Supply Ability : 350 units/year
    • Product Details
    • Company Profile

    6×4 Driving Single Cab Hydraulic Aerial Ladder Fire Truck with full power PTO

    6×4 Driving Single Cab Hydraulic Aerial Ladder Fire Truck with full power PTO


    Vehicle


    Dimension (L×W×H)10500×2500×3980 (mm)
    Gross weight32100 (kg)
    Complete vehicle shipping mass31950(kg)
    Seat (inc. driver)2
    Engine Power320/435(kw/hp)

    Chassis


    ManufacturerMercedes Benz
    ModelActros3344
    Driving6×4
    CabinSingle cab
    Wheel base4500+1350 (mm)
    Net weight9230Kg
    Max. loading23700Kg
    Max. running speed90Km/h
    Min. turning diameter<22.3m
    Engine typeV type, 6 cylinder in line turbo, middle cool engine
    ModelMercedes OM501 LA
    Max. engine power320Kw/ 1800r/min
    Maximum torque2100N.M/1080rpm
    Emission standardEuro V
    ClutchMonolithic, Dry
    Transmission

    Mercedes G240-16

    fully synchronized

    Full power PTO


    NMV200(N56)i=1.48(speedup), Full power

    PTO of transmission


    MB-NA121-1b(N04)i=1.03/1.24 (speed up)


    FAQ:

    1. Q:Are you a factory or a trade company?

    A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.


    2. Q:Where is your factory located?

    A:We are located in Shanghai Province,China.


    3. Q:What's your payment method?

    A: T/T and L/C are preferred.


    4.Q:Do you arrange shipment for the vehicles?

    A:Yes, we can arrange shippment based on trade terms.


    5. Q: How is the packing?

    A:All the packing comply with exporting standard.


    Any other questions, please do not hesitate to contact with us.
