    6x4 Driving Aerial Ladder Platform Fire Truck with 5000kg Water 2000kg Foam

    Ask Lasest Price
    Brand Name : Jindun
    Model Number : DG44
    Certification : ISO9001/CCC
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : 150 days
    Supply Ability : 350 units/year
    • Product Details
    • Company Profile

    6x4 Driving Aerial Ladder Platform Fire Truck with 5000kg Water 2000kg Foam

    6x4 Driving Aerial Ladder Platform Fire Truck with 5000kg Water 2000kg Foam




    Boom Structure


    Main boom + four telescopic booms + one folding boom, welded with HG70 high-strength steel
    Max. working height44m
    Max. working range21m
    Main boom action angle-3°~83°
    Folding boom action angle0°~180°
    Turntable slewingInfinite rotation 360°
    Rated Pump flow70L/s@1.7Mpa
    Boom extending time≤140s
    Outrigger extending time≤35s
    Hydraulic system pressure21MPa
    Max. wind velocity12.5m/s
    Outrigger longitudinal and transverse5600×5300mm
    Fire fighting system

    Fire-fighting performance data


    Range(water/ foam)≥70/60m
    Foam proportioner6%(manual adjustment)
    Liquid tank
    ManufacturerShanghai Jindun
    CapacityWater: 5000kg Foam: 2000kg
    MaterialStainless steel 304
    StructureShock-reducing rubber resilient mounting, set vertical and horizontal anti swing plate on subframe
    Device

    2 manhole, with fast locking and opening device

    2 fluid level gauge

    2 drain outlet, with stainless steel ball valve

    1 inner filling pipe end

    4 outer filling pipe end

    PipelineWater outlet

    4×DN80 ball value coupling


    Suction inlet1×DN150 hermaphroditic coupling with lid cover(left side)
    Water supply

    2×DN80 ball value coupling


    Liquid inlet

    1×DN50 manual ball valve(left side)


    Water outlet out of the platform1×DN65 ball value coupling(in front of platform)
    Coupling type: quick coupling


    FAQ:

    1. Q:Are you a factory or a trade company?

    A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.


    2. Q:Where is your factory located?

    A:We are located in Shanghai Province,China.


    3. Q:What's your payment method?

    A: T/T and L/C are preferred.


    4.Q:Do you arrange shipment for the vehicles?

    A:Yes, we can arrange shippment based on trade terms.


    5. Q: How is the packing?

    A:All the packing comply with exporting standard.


    Any other questions, please do not hesitate to contact with us.
