    Brigade Hose Reel Water Dry Power and Foam Fire Truck 6.45m Lifting 4x2 Drive

    Ask Lasest Price
    Brand Name : CIMC
    Model Number : JY98
    Certification : ISO9001,CCC
    Price : Factory price, negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 350 units/year
    Delivery Time : 180 days
    • Product Details
    • Company Profile

    Brigade Hose Reel Water Dry Power and Foam Fire Truck 6.45m Lifting 4x2 Drive

    Brigade Hose Reel Water Dry Power and Foam Fire Truck 6.45m Lifting 4x2 Drive


    Chassis

    ManufacturerMAN
    ModelTGS33.400
    Drive type6x4
    Emission standardEuro 3
    Max. total mass15000kg
    PTOSuitable for pump operation
    Engine ModelMAN D2066LF49
    Max. power294kw

    Fire pump

    ManufacturerRosenbauer
    ModelR600
    Flow90L/s
    Pressure1.0MPa
    Water diversionPiston primer pump
    Max. vacuum degree≥85 kPa
    Priming time≤80s
    Auto ring pump foamPH48x2
    TypeManual
    Mixing ratio3%, 6%

    Dry powder tank

    Dry powder filling capacity500Kg
    Working pressure1.2 ~ 1.4MPa
    Dry powder gun and hose reel2 sets (30m)
    Effective spray rate5Kg/s
    Shot range≥12m

    • Dry powder tank is a pressure vessel which is mainly welded by Q345R material. It is made of feeding powder port, discharging powder port, nitrogen delivery pipe and discharge powder tube, tank nitrogen delivery pipe is a ring shape which is equipped with multiple intake valves, so that gas and powder can mixing uniformly, with fluidized state. The design of intake valve makes dry powder be inaccessible to nitrogen gas delivery pipe.
    • Pressure reducing valve and safety valve :This device use Chinese reducing valve. It is a special pressure reducing valve of dry powder fire extinguishing equipment which has features of reliable performance, small size, large gas supply, safety and convenience.
    • Dry powder system control box :Equipped with air source main valve, air filter, in the electric steering box is equipped with solenoid valve, fuse boxes, relay, binding post and so on.
    Brigade Hose Reel Water Dry Power and Foam Fire Truck 6.45m Lifting 4x2 Drive
