Shanghai Jindun 30 Pieces Emergency Rescue Truck
(5 Person Fire Equipment Truck)
The emergency rescue fire truck is reformed from TGM 18.290 chassis
(National IV emission) produced by MAN Commercial Vehicle Co., Ltd.
It is equipped with Hiab 122b-2clx truck mounted crane produced by
Hiab company of Finland, m12000 winch produced by warn company of
America, ns6.4-20-4000 lifting lighting system produced by WB
company of America, eh3135 generator of Honda and other lighting
and emergency equipment. It is suitable for public security fire
brigade in large and medium-sized cities, petrochemical
enterprises, airports and other professional fire brigade to deal
with emergency. The shape, structure and performance of maintenance
system of the whole vehicle meet the level and service life
requirements of similar imported vehicles abroad.
Product Parameter
Chassis
| Manufacturer | MAN |
| Model | TGM 18.290 |
| Drive type | 4x2 |
| Cab | Crew cab |
| Wheelbase | 4425mm |
| Max. total mass | 18000kg |
| Max. speed | 96km/h |
| Min. turning diameter | <15.6m |
| Engine type | In-line six-cylinder, inter-cooling, high pressure common rail,
electronic control |
| Model | D0836LFL30 |
| Max. power | 213kw |
| Max. torque | 1150N.M |
| Emission standard | China IV |
| Gearbox model | ZF 9S-1310 OD Manual |
Lift lighting system
| Manufacturer | American WB imported with original packaging |
| Model | NS6.4-20-4000 |
| Above ground level | 8m |
| Classification of wind resistance | 110km/h(China level 11) |
| Lamps specification | Quartz halogen lamp |
| Lifter material | Maraging 6061 T6 |
| Lamps power | 4×1000w |
| Lamps horizontal rotating angle | 360° |
| Lamps vertical rotating angle | 360° |
| Lighting life | ≥2000 hours |
| Illumination | ≥86000lx |
| Contraction time | ≤60S |
| Warranty period | 2 years |
| Remote control type | Drive by wire |
| Specialty | Master reset function |
Company Profile:
Jindun as a member of China Fire Protection Association, was
certified by TUV System, NFPA and CCCF. By excellent products and
innovative technology, we are engaged in developing a “safe,
livable and rich society.”
The company specializes in R & D and production of ladder cars,
high pressure jet trucks, rail dual purpose fire engines, remote
water supply vehicles, climbing platform vehicles, water tank foam
cars, AT cars, emergency rescue vehicles, marine fire engines,
anti-chemical detection vehicles, anti-chemical and decontamination
vehicles, CAFS fire engines, airport fire engines, unmanned
fire-fighting tankers, lighting fire engines, gas trucks, etc., and
according to the changes of fire market and customer demand,
Continue to develop high-end special fire engines and
multifunctional and intelligent fire-fighting equipment.
