    Shanghai Jindun Telescopic Boom Platform Aerial Ladder Fire Truck 8x4 Drive

    Shanghai Jindun Telescopic Boom Platform Fire Truck

    (Chassis: VOLVO Drive: 8x4)


    Product Introduction:


    1. The main hydraulic pump system uses variable displacement pump to ensure the accurate oil supply and stability of the hydraulic system. During the operation of the boom, the hydraulic pump can automatically determine the oil supply according to the amount of oil required for the boom movement, thus preventing the oil system temperature from being too high to damage the hydraulic system and ensuring the stability of the boom movement.

    2. Unique computerized control system, TP-5 Intelligent fire control system,This allows more direct control and more agile operation. Dual CPU controller and double level safe software calculation structure, dual redundancy sensor, dual CAB cable communication, and multiple point redundancy operating panel. Diagnosisand analysis in time for vehicle safety.

    The system consist of 4 branch system:

    Water pipe control system realize the data interchange of the firefighting, pump pressure control and engine.


    Product Parameter:


    Vehicle modelDG70
    chassischassisVOLVO FM540 84R(made in Europe)
    Driving8×4
    Wheel base1995+4205+1370mm
    engineEuro V emission standard
    power540hp/397Kw/1,450-1,900rpm
    Engine capacity11.946 L
    Fuel tank315 L tank
    Urea tank48L Adblue urea tank
    tire

    Front wheel: 385/65 R22.5 (4 pieces)

    rear wheel: 315/80 R22.5 (9 pieces)

    spare tire is same with driving wheel

    Battery box110A generator,2X12V/170AH battery
    cabM-cab,1+1 seating

    Hydraulic tilting type VOLVO safety cab, comfortable (suspension) driver seat, fire red paint, radio, CD player, hot and cold air conditioning system, central door lock, electric doors and Windows, electric rearview mirror, front view mirror, driving outdoor visor, safety belt.

    Integrated power steering, cruise control system, real-time monitoring system for vehicle operation, engine start preheater, reversing warning device, oil and water separator for fuel system, brake air dryer, etc

    Dimension:(L×W×H)13600×2500×3900mm
    Full mass42600kg
    Max running≥85km/h
    outriggerstructureH style
    longitudinal8690mm
    transverse7035mm
    Outrigger levelingAuto leveling+ manual leveling
    Working cage load500kg
    Max. Working height70m
    Max. Working radius24m
    Boom structure6down telescopic boom+2 up telescopic boom
    Boom action angle

    Down boom 0°——88°

    Down and up boom 0°——170°

    Rotation range360°full rotation
    Outrigger extending time≤50s
    Time of Boom raise up at rate height and rotation with 90 °≤310s
    Water system
    pump

    American WATEROUS CX centrifugal fire pump

    flow:100 L/S @ 1.0 Mpa80 L/S @ 1.60Mpa

    Inlet flange:DN150,outlet flange:DN100

    Fire monitor

    American Elkhart:Scorpion RF 8294-EXM+SM-1250E,water/foam use electronic control monitor.

    Flow adjustment 1150——4800L/min;working pressure 0.55MPa.

    reach(water)≥55m. reach(foam)≥50m.(the reach will be different depending on water flow)

    Swivel angle ±45 degree; up angle 90 degree;depression angle 35degree.

    ≥100 m wireless control .

    Foam headEquip with foam monitor head
    Water way control

    Water way control mode:pneumatic control

    The position is left side of vehicle



    Company Profile:


    Jindun as a member of China Fire Protection Association, was certified by TUV System, NFPA and CCCF. By excellent products and innovative technology, we are engaged in developing a “safe, livable and rich society.”


    The company specializes in R & D and production of ladder cars, high pressure jet trucks, rail dual purpose fire engines, remote water supply vehicles, climbing platform vehicles, water tank foam cars, AT cars, emergency rescue vehicles, marine fire engines, anti-chemical detection vehicles, anti-chemical and decontamination vehicles, CAFS fire engines, airport fire engines, unmanned fire-fighting tankers, lighting fire engines, gas trucks, etc., and according to the changes of fire market and customer demand, Continue to develop high-end special fire engines and multifunctional and intelligent fire-fighting equipment.
